Cessna Citation X

Citation X

Cessna · 1996 – 2012

3,140 NM

Range

525 kts

Cruise

9

Passengers

3D

Overview / 01

Key Facts

The Cessna Citation X is a large jet manufactured by Cessna between 1996 and 2012.
The Cessna Citation X is powered by two Rolls Royce AE 3007C1 engines, resulting in an hourly fuel burn of 336 Gallons per Hour.
Capable of cruising at up to 525 knots, the Cessna Citation X can fly non-stop for up to 3140 nautical miles.
The aircraft can carry up to 9 passengers.
The Cessna Citation X has an estimated hourly charter price of $6000, with a new list price of $23 million at the time of manufacture.

History / 02

Overview & History

The Cessna Citation X, a medium-sized long-range business jet, marked the launch of the all-new 750 series, taking over the well-established 650 series.

It was considered a completely new aircraft, made from scratch in all major aspects, and not an upgraded version of previous Citation Jet aircraft.

As of February 2018, 75% of Citation X aircraft were purchased pre-owned by their current owners, the other 25% new. 10.4% are for sale with more than half of those (69%) under an exclusive broker agreement.

When for sale, the average time on the market is 373 days.

The Citation X was announced at the NBAA Convention in October 1990 with the first prototype taking flight in December 1993. The first delivery of the Citation X occurred in July 1996 to golfer and devoted Cessna customer, Arnold Palmer.

A total of 315 Citation X aircraft have been manufactured with 309 currently in operation worldwide. An updated version called the New Citation X+ was launched in 2010 featuring upgraded engines and advanced avionics systems.

Deliveries of the new Citation X+ started in 2013 and there are currently 27 in operation worldwide.

In Service

303

Total Built

315

Production

1996 – 2012

Performance / 03

Cessna Citation X Performance

Range

3,140NM

Cruise Speed

525kts

Ceiling

51,000ft

Fuel Burn

336GPH

Range by Configuration

Standard range (typical load)3,140 NM
Full-seat range (9 pax)2,890 NM
Ferry range (no payload)3,125 NM

26 NM per additional passenger

Takeoff Distance

5,250 ft

Landing Distance

2,816 ft

Rate of Climb

3,650 fpm

At the time of its design, engineers all over the private jet industry were being pressured to create more reliable, higher-performing products that operated at a drastically lower cost.

Rolls-Royce certainly met the requirements in the creation of the high-bypass AE3007C1 turbofan engine, which delivers 8,600 pounds of thrust.

It was later fine-tuned specifically for the Citation X to run at a lower temperature so that the jet could run its engines longer.

The engines on the Citation X had the highest thrust-to-weight ratio available at that time as well as the lowest specific fuel consumption for a private jet in its class. Getting the Citation X to cruise at .90 Mach was no small feat.

Aerospace engineers spent months analyzing the jet’s aerodynamic structure with computational fluid dynamics computer technology.

The range of the Citation X is 3,111 nm operating under NBAA IFR 4 passengers with available fuel. It uses 325 gallons of fuel per hour.

Comfort / 04

Cessna Citation X Interior

Toilet Shower Flat Floor Dedicated Bed Baggage Access

Even considering that the Citation X is the fastest midsize jet in the world, Cessna did not neglect to design a comfortable and luxurious cabin to complete the package.

At the time of the aircraft’s release, the Citation X had the largest cabin out of any Citation model before it. Its interior dimensions of 23′ 11″ cabin length, 5′ 6″ cabin width, and 5′ 8″ cabin height provide ample space to relax and stretch out.

Typically seating eight passengers in a spacious executive seating configuration, the Citation X can also carry a maximum of twelve passengers in a higher-density seating arrangement.

Introducing a large lavatory, a fully functional galley, and a spacious closet, passengers will find Cessna took great care to accommodate their needs during the flight.

The Citation X also provides over 80 cubic feet of storage space in a well-heated and properly pressurized baggage compartment, effectively preventing damage to the cargo regardless of external weather conditions.

In short, Cessna has designed a comfortable executive cabin to complement the definitively impressive high speeds that the Citation X has become known for.

A bathroom, large enough to double as a dressing room, is located at the rear of the private jet and a closet, large enough to store garment bags, is within reach.

Cabin Length

23.88ft

Cabin Width

5.51ft

Cabin Height

5.71ft

Cabin Environment

Cabin altitude at cruise8,000 ft

Standard

Pressure differential64.12 psi
Sea-level cabin up to25,230 ft

Noise compliance (dB) — lower is quieter

Lateral83 dB / limit 103
Flyover72.3 dB / limit 89
Approach90.3 dB / limit 98

Technology / 05

Cockpit

AvionicsHoneywell Primus 2000

Of course, no discussion of Cessna’s private jets would be complete without mentioning their choice of avionics – in this case, the Honeywell Primus 2000 autopilot/flight director system.

This system has five 7×8 inch screens that replace standard analog instruments with a clean, easy-to-read EICAS display.

It has a dual flight management system and comes standard with Honeywell GPS. In 2004 Cessna announced that Enhanced Vision System: a useful tool which uses infrared sensors to create a visual for the pilot when flying IFR (Instrument Flight Rules), such as during snow and rainstorms, fog, or at night as an option on the Citation X.

Engine

Rolls-Royce

AE3007C1

Crew Training

Initial: 19 days

Recurrent: 5 days

Min. Pilots

2

Charter / 06

Cessna Citation X Charter Cost

Estimated Hourly Charter Rate

$5,117/ hr

Actual rates vary by route, season and operator

This jet is one of the most luxurious jets available for charter flights from and to New York, with a wide range of availability in several major aviation markets.

The cost to charter this jet starts at around $5,900 an hour. Hourly charter rates do not include all taxes, fuel, and other fees.

Charter costs will vary based on year of make/model, schedule, routing, passenger & baggage totals, and other factors.

Charter rate$5,117 / hr
Hourly ownership$6,344
Hourly fuel$3,162
Maintenance$1,690
Engine overhaul$638
Ground fees$250

Market / 07

Purchase Cost

New List Price

$23,000,000

Avg. Pre-Owned

$6,282,000

Annual Cost

$1,571,935

Charter / hr

$5,117

New vs Pre-Owned

New list price$23,000,000
Avg. pre-owned$6,282,000

Save $16,718,000 (73%) buying pre-owned

Depreciation rate4.17% / year

Hourly Cost Comparison

Charter rate (revenue)$5,117 / hr
Ownership cost (expense)$4,554 / hr

↑ Charter revenue exceeds ownership cost by $563 / hr

The acquisition cost for this jet typically ranges from $21 million.

The price of a jet depends on the production year; it can also go above the given range if the production is new. It will cost buyers around $2 million per year which includes fuel, crew members, and maintenance, etc.

The price of a pre-owned aircraft can be within $10-15 million. There are numerous sellers available on various sites.

Value History

Pre-owned market value over time

$8.8M2012
$4.4M$6.6M$8.8M19961997199819992000200120022003200420052006200720082009201020112012

Maintenance Schedule

Details / 08

In-Depth

Performance / 09

Performance

Performance Specs

Range3,140 NM
Cruise speed525 kts
Long range cruise470 kts
Max altitude51,000 ft
Takeoff distance5,250 ft
Landing distance2,816 ft

Comfort / 10

Comfort

Comfort Specs

Max passengers9
Typical passengers8
Cabin volume752 cf
Baggage capacity82 cf
Est. charter rate$5,117
Avg. pre-owned$6,282,000

Details / 11

Weights

Weights Specs

MTOW36,100 lbs
Max ramp weight36,400 lbs
Max landing weight31,800 lbs
Max payload2,375 lbs
Available fuel12,931 lbs

Details / 12

Dimensions

Dimensions Specs

Cabin length23.88 ft
Cabin width5.51 ft
Cabin height5.71 ft
Exterior length72.31 ft
Wingspan63.91 ft
Exterior height19.19 ft

Details / 13

Power

Power Specs

Engine manufacturerRolls-Royce
Engine modelAE3007C1
Thrust output6,442 lbs
Total thrust12,884 lbs
Fuel burn336 GPH
Production1996 – 2012

Range / 14

Range Map

Cessna Citation X Range Map
